Email not DKIM Signed (dkim=none reason="message not signed")

Wazza · June 24, 2022, 6:38am

Hi Guys

I have been struggling to get DKIM working on my server. I have created the DNS records at cloudflare and have confirmed that they are correct but the messages don’t appear to be signed with DKIM when they are sent. Is there anything I can do to get this working?

Any help will be greatly appreciated.

Here is the message from my port25-com test: (I cant post links so had to remove all urls and email addresses)

The Port25 Solutions, Inc. team

==========================================================
Summary of Results

SPF check: pass
“iprev” check: pass
DKIM check: none

DKIM check details:

Result: none (message not signed)
ID(s) verified:

NOTE: DKIM checking has been performed based on the latest DKIM specs
(RFC 4871 or draft-ietf-dkim-base-10) and verification may fail for
older versions. If you are using Port25’s PowerMTA, you need to use
version 3.2r11 or later to get a compatible version of DKIM.

==============================================================
Explanation of the possible results (based on RFCs 7601, 7208)

DKIM Results

none: The message was not signed.

pass: The message was signed, the signature or signatures were
acceptable to the ADMD, and the signature(s) passed verification
tests.

fail: The message was signed and the signature or signatures were
acceptable to the ADMD, but they failed the verification test(s).

policy: The message was signed, but some aspect of the signature or
signatures was not acceptable to the ADMD.

neutral: The message was signed, but the signature or signatures
contained syntax errors or were not otherwise able to be
processed. This result is also used for other failures not
covered elsewhere in this list.

temperror: The message could not be verified due to some error that
is likely transient in nature, such as a temporary inability to
retrieve a public key. A later attempt may produce a final
result.

permerror: The message could not be verified due to some error that
is unrecoverable, such as a required header field being absent. A
later attempt is unlikely to produce a final result.

Original Email:

Return-Path:
Received: from XXXXX (XXXXX) by verifier-port25-com id hmlcjk2p2to5 for ; Fri, 24 Jun 2022 06:27:06 +0000 (envelope-from )
Authentication-Results: XXXXX; spf=pass smtp-mailfrom=XXXXX;
iprev=pass (matches XXXXX) policy.iprev=x.x.x.x;
dkim=none reason=“message not signed”
Received: from XXXXX ([127.0.0.1] helo=XXXXX)
by xx.xxx.com with esmtpa (Exim 4.93)
(envelope-from )
id 1o4cmX-007wGy-4x
for XXXXX; Fri, 24 Jun 2022 16:27:05 +1000
MIME-Version: 1.0
Date: Fri, 24 Jun 2022 16:27:05 +1000
From: XXXXX
To: XXXXX
Subject: Testing sending from webmail
Message-ID:
X-Sender: XXXXX

eris · June 24, 2022, 8:41am

Just ran a test:

Thank you for using the verifier,

The Port25 Solutions, Inc. team

==========================================================
Summary of Results

SPF check: pass
“iprev” check: pass
DKIM check: pass

Did you copy the DNS records from:

DNS records option in List mail?

Wazza · June 24, 2022, 9:02am

Hi Eris

Yes I have copied the records from DNS in hestiaCP and replicated them in CloudFlare DNS.

eris · June 24, 2022, 9:13am

DKIM enabled in the mail settings?

Wazza · June 26, 2022, 12:07pm

Yes, all enabled and showing that it should work…

Wazza · June 26, 2022, 12:11pm

Sorry, can only upload one image per post
DNS at cloudflare:

Wazza · June 26, 2022, 12:12pm

DNS in Hestia which has been replicated in cloudflare:

Wazza · June 28, 2022, 1:59am

@eris Do you have any other suggestions? I feeling that exim may not be signing the message as it is sent, but not sure how to check or test?

Wazza · July 28, 2022, 3:31am

Hi Guys

I still have the same issue. Is there something stopping the emails from being signed in the exim.conf.template?

######################################################################

Exim configuration file for Hestia Control Panel

######################################################################

SPAMASSASSIN = yes
SPAM_SCORE = 50
SPAM_REJECT_SCORE = 100
CLAMD = yes

smtp_banner = XXXXX
smtp_active_hostname = XXXXX
add_environment = <; PATH=/bin:/usr/bin
keep_environment =
disable_ipv6 = true

domainlist local_domains = dsearch;/etc/exim4/domains/
domainlist relay_to_domains = dsearch;/etc/exim4/domains/
hostlist relay_from_hosts = 127.0.0.1
hostlist whitelist = net-iplsearch;/etc/exim4/white-blocks.conf
hostlist spammers = net-iplsearch;/etc/exim4/spam-blocks.conf
no_local_from_check
untrusted_set_sender = *
acl_smtp_connect = acl_check_spammers
acl_smtp_mail = acl_check_mail
acl_smtp_rcpt = acl_check_rcpt
acl_smtp_data = acl_check_data
acl_smtp_mime = acl_check_mime

.ifdef SPAMASSASSIN
spamd_address = 127.0.0.1 783
.endif

.ifdef CLAMD
av_scanner = clamd: /var/run/clamav/clamd.ctl
.endif

log_selector = +tls_sni

tls_advertise_hosts = *

We test that $tls_in_sni is a valid domain, by an arbitrary email address [email protected] .

Then, we extract the domain with a function that would fail if the email address is invalid.

If the certificate exists, we will use it, otherwise the default certificate in /etc/ssl will be used.

tls_certificate =
${if and {
{ eq {${domain:foo@$tls_in_sni}} {$tls_in_sni}}
{ exists{/usr/local/hestia/ssl/mail/$tls_in_sni.crt} }
}
{/usr/local/hestia/ssl/mail/$tls_in_sni.crt}
{/usr/local/hestia/ssl/certificate.crt}
}

tls_privatekey =
${if and {
{ eq {${domain:foo@$tls_in_sni}} {$tls_in_sni}}
{ exists{/usr/local/hestia/ssl/mail/$tls_in_sni.key} }
}
{/usr/local/hestia/ssl/mail/$tls_in_sni.key}
{/usr/local/hestia/ssl/certificate.key}
}

daemon_smtp_ports = 25 : 465 : 587
tls_on_connect_ports = 465
never_users = root
host_lookup = *
rfc1413_hosts = *
rfc1413_query_timeout = 0s
ignore_bounce_errors_after = 2d
timeout_frozen_after = 7d

DKIM_DOMAIN = ${lc:${domain:$h_from:}}
DKIM_FILE = /etc/exim4/domains/${lc:${domain:$h_from:}}/dkim.pem
DKIM_PRIVATE_KEY = ${if exists{DKIM_FILE}{DKIM_FILE}{0}}

OUTGOING_IP = /etc/exim4/domains/$sender_address_domain/ip

SMTP_RELAY_FILE = ${if exists{/etc/exim4/domains/${sender_address_domain}/smtp_relay.conf}{/etc/exim4/domains/$sender_address_domain/smtp_relay.conf}{/etc/exim4/smtp_relay.conf}}
SMTP_RELAY_HOST = ${lookup{host}lsearch{SMTP_RELAY_FILE}}
SMTP_RELAY_PORT = ${lookup{port}lsearch{SMTP_RELAY_FILE}}
SMTP_RELAY_USER = ${lookup{user}lsearch{SMTP_RELAY_FILE}}
SMTP_RELAY_PASS = ${lookup{pass}lsearch{SMTP_RELAY_FILE}}

Custom Filter

system_filter = /etc/exim4/system.filter
system_filter_user = Debian-exim

######################################################################

ACL CONFIGURATION

Specifies access control lists for incoming SMTP mail

######################################################################

acl_not_smtp = acl_not_smtp

begin acl

Limit per user for PHP scripts

acl_not_smtp:
deny message = Website of user $authenticated_id is sending too many emails - rate overlimit = $sender_rate / $sender_rate_period
ratelimit = 200 / 1h / $authenticated_id

warn ratelimit = 100 / 1h / strict / $authenticated_id
log_message = Sender rate [limitlog]: log / account / $authenticated_id / $sender_rate / $sender_rate_period

accept

acl_check_spammers:
accept hosts = +whitelist

drop message = Your host in blacklist on this server.
log_message = Host in blacklist
hosts = +spammers

accept

acl_check_mail:
deny condition = ${if eq{$sender_helo_name}{}}
message = HELO required before MAIL

drop message = Helo name contains an IP address (HELO was $sender_helo_name) and not is valid
condition = ${if match{$sender_helo_name}{\N((\d{1,3}[.-]\d{1,3}[.-]\d{1,3}[.-]\d{1,3})|([0-9a-f]{8})|([0-9A-F]{8}))\N}{yes}{no}}
condition = ${if match {${lookup dnsdb{>: defer_never,ptr=$sender_host_address}}}{$sender_helo_name}{no}{yes}}
delay = 45s

drop condition = ${if isip{$sender_helo_name}}
message = Access denied - Invalid HELO name (See RFC2821 4.1.3)

drop condition = ${if eq{[$interface_address]}{$sender_helo_name}}
message = $interface_address is my address

accept

acl_check_rcpt:
accept hosts = :

Limit per email account for SMTP auhenticated users

deny message = Email account $authenticated_id is sending too many emails - rate overlimit = $sender_rate / $sender_rate_period
set acl_c_msg_limit = ${if exists{/etc/exim4/domains/${lookup{${domain:$authenticated_id}}dsearch{/etc/exim4/domains/}}/limits}{${lookup {$authenticated_id} lsearch{/etc/exim4/domains/${lookup{${domain:$authenticated_id}}dsearch{/etc/exim4/domains/}}/limits}{$value}{${readfile{/etc/exim4/limit.conf}}}}}{${readfile{/etc/exim4/limit.conf}}} }
ratelimit = $acl_c_msg_limit / 1h / strict/ $authenticated_id

warn ratelimit = ${eval:$acl_c_msg_limit / 2} / 1h / strict / $authenticated_id
log_message = Sender rate [limitlog]: log / email / $authenticated_id / $sender_rate / $sender_rate_period

deny message = Restricted characters in address
domains = +local_domains
local_parts = ^[.] : ^.*[@%!/|]

deny message = Restricted characters in address
domains = !+local_domains
local_parts = ^[./|] : ^.[@%!] : ^./\.\./

require verify = sender

accept hosts = +relay_from_hosts
control = submission

accept authenticated = *
control = submission/domain=

deny message = Rejected because $sender_host_address is in a black list at $dnslist_domain\n$dnslist_text
hosts = !+whitelist
dnslists = ${readfile {/etc/exim4/dnsbl.conf}{:}}

require message = relay not permitted
domains = +local_domains : +relay_to_domains

deny message = smtp auth required
sender_domains = +local_domains
!authenticated = *

require verify = recipient

.ifdef CLAMD
warn set acl_m0 = no

warn condition = ${if exists {/etc/exim4/domains/$domain/antivirus}{yes}{no}}
set acl_m0 = yes
.endif

.ifdef SPAMASSASSIN
warn set acl_m1 = no
set acl_m3 = no

warn condition = ${if exists {/etc/exim4/domains/$domain/antispam}{yes}{no}}
set acl_m1 = yes
warn condition = ${if exists {/etc/exim4/domains/$domain/reject_spam}{yes}{no}}
set acl_m3 = yes
.endif

accept

acl_check_data:
.ifdef CLAMD
deny message = Message contains a virus ($malware_name) and has been rejected
malware = */defer_ok
condition = ${if eq{$acl_m0}{yes}{yes}{no}}
.endif

.ifdef SPAMASSASSIN
warn !authenticated = *
hosts = !+relay_from_hosts
condition = ${if < {$message_size}{1024K}}
condition = ${if eq{$acl_m1}{yes}{yes}{no}}
spam = debian-spamd:true/defer_ok
add_header = X-Spam-Score: $spam_score_int
add_header = X-Spam-Bar: $spam_bar
add_header = X-Spam-Report: $spam_report
set acl_m2 = $spam_score_int

warn condition = ${if !eq{$acl_m2}{} {yes}{no}}
condition = ${if >{$acl_m2}{SPAM_SCORE} {yes}{no}}
add_header = X-Spam-Status: Yes
message = SpamAssassin detected spam (from $sender_address to $recipients).

Deny spam at high score if spam score > SPAM_REJECT_SCORE and delete_spam is enabled

deny message = This message scored $spam_score spam points
spam = debian-spamd:true
condition = ${if eq{$acl_m3}{yes}{yes}{no}}
condition = ${if >{$spam_score_int}{SPAM_REJECT_SCORE}{1}{0}}
.endif

accept

acl_check_mime:
deny message = Blacklisted file extension detected
condition = ${if match {${lc:$mime_filename}}{\N(.ace|.ade|.adp|.app|.arj|.asp|.aspx|.asx|.bas|.bat|.cab|.cer|.chm|.cmd|.cnt|.com|.cpl|.crt|.csh|.der|.diagcab|.dll|.efi|.exe|.fla|.fon|.fxp|.gadget|.grp|.hlp|.hpj|.hta|.htc|.img|.inf|.ins|.iso|.isp|.its|.jar|.jnlp|.js|.jse|.ksh|.lib|.lnk|.mad|.maf|.mag|.mam|.maq|.mar|.mas|.mat|.mau|.mav|.maw|.mcf|.mda|.mdb|.mde|.mdt|.mdw|.mdz|.msc|.msh|.msh1|.msh1xml|.msh2|.msh2xml|.mshxml|.msi|.msp|.mst|.msu|.ops|.osd|.pcd|.pif|.pl|.plg|.prf|.prg|.printerexport|.ps1|.ps1xml|.ps2|.ps2xml|.psc1|.psc2|.psd1|.psdm1|.pst|.py|.pyc|.pyo|.pyw|.pyz|.pyzw|.reg|.scf|.scr|.sct|.sfx|.shb|.shs|.swf|.sys|.theme|.tmp|.ttf|.url|.vb|.vba|.vbe|.vbp|.vbs|.vhd|.vhdx|.vsmacros|.vsw|.vxd|.webpnp|.website|.wim|.ws|.wsc|.wsf|.wsh|.xbap|.xll|.xnk)$\N}{1}{0}}

accept

######################################################################

AUTHENTICATION CONFIGURATION

######################################################################
begin authenticators

smtp_relay_login:
driver = plaintext
public_name = LOGIN
hide client_send = : SMTP_RELAY_USER : SMTP_RELAY_PASS

dovecot_plain:
driver = dovecot
public_name = PLAIN
server_socket = /var/run/dovecot/auth-client
server_set_id = $auth1

dovecot_login:
driver = dovecot
public_name = LOGIN
server_socket = /var/run/dovecot/auth-client
server_set_id = $auth1

######################################################################

ROUTERS CONFIGURATION

Specifies how addresses are handled

######################################################################
begin routers

send_via_unauthenticated_smtp_relay:
driver = manualroute
address_data = SMTP_RELAY_HOST:SMTP_RELAY_PORT
domains = !+local_domains
require_files = SMTP_RELAY_FILE
condition = ${if eq{SMTP_RELAY_USER}{}}
transport = remote_smtp
route_list = * ${extract{1}{:}{$address_data}}::${extract{2}{:}{$address_data}}
no_more
no_verify

send_via_smtp_relay:
driver = manualroute
address_data = SMTP_RELAY_HOST:SMTP_RELAY_PORT
domains = !+local_domains
require_files = SMTP_RELAY_FILE
transport = smtp_relay_smtp
route_list = * ${extract{1}{:}{$address_data}}::${extract{2}{:}{$address_data}}
no_more
no_verify

dnslookup:
driver = dnslookup
domains = !+local_domains
transport = remote_smtp
no_more

userforward:
driver = redirect
check_local_user
file = $home/.forward
require_files = ${local_part}:+${home}/.forward
domains = +local_domains
allow_filter
no_verify
no_expn
check_ancestor
file_transport = address_file
pipe_transport = address_pipe
reply_transport = address_reply

procmail:
driver = accept
check_local_user
require_files = ${local_part}:+${home}/.procmailrc:/usr/bin/procmail
transport = procmail
no_verify

autoreplay:
driver = accept
require_files = /etc/exim4/domains/$domain/autoreply.${local_part}.msg
condition = ${if exists{/etc/exim4/domains/$domain/autoreply.${local_part}.msg}{yes}{no}}
retry_use_local_part
transport = userautoreply
unseen

aliases:
driver = redirect
headers_add = X-redirected: yes
data = ${extract{1}{:}{${lookup{$local_part@$domain}lsearch{/etc/exim4/domains/$domain/aliases}}}}
require_files = /etc/exim4/domains/$domain/aliases
redirect_router = dnslookup
pipe_transport = address_pipe
unseen

localuser_fwd_only:
driver = accept
transport = devnull
condition = ${if exists{/etc/exim4/domains/$domain/fwd_only}{${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/fwd_only}{true}{false}}}}

localuser_spam:
driver = accept
transport = local_spam_delivery
condition = ${if eq {${if match{$h_X-Spam-Status:}{\N^Yes\N}{yes}{no}}} {${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}{yes}{no_such_user}}}}

localuser:
driver = accept
transport = dovecot_virtual_delivery
condition = ${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}{true}{false}}

catchall:
driver = redirect
headers_add = X-redirected: yes
require_files = /etc/exim4/domains/$domain/aliases
data = ${extract{1}{:}{${lookup{*@$domain}lsearch{/etc/exim4/domains/$domain/aliases}}}}
file_transport = local_delivery
redirect_router = dnslookup

terminate_alias:
driver = accept
transport = devnull
condition = ${lookup{$local_part@$domain}lsearch{/etc/exim4/domains/$domain/aliases}{true}{false}}

######################################################################

TRANSPORTS CONFIGURATION

######################################################################
begin transports

smtp_relay_smtp:
driver = smtp
hosts_require_auth = $host_address
hosts_require_tls = $host_address

remote_smtp:
driver = smtp
helo_data = XXXXX
dkim_selector = mail
dkim_private_key = DKIM_PRIVATE_KEY
dkim_canon = relaxed
dkim_strict = true
hosts_try_fastopen = !*.l.google.com
interface = ${if exists{OUTGOING_IP}{${readfile{OUTGOING_IP}}}}

procmail:
driver = pipe
command = “/usr/bin/procmail -d $local_part”
return_path_add
delivery_date_add
envelope_to_add
user = $local_part
initgroups
return_output

local_delivery:
driver = appendfile
maildir_format
maildir_use_size_file
user = ${extract{2}{:}{${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}}}}
group = mail
create_directory
directory_mode = 770
mode = 660
use_lockfile = no
delivery_date_add
envelope_to_add
return_path_add
directory = “${extract{5}{:}{${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}}}}/mail/$domain/$local_part”
quota = ${extract{6}{:}{${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}}}}M
quota_warn_threshold = 75%

local_spam_delivery:
driver = appendfile
maildir_format
maildir_use_size_file
user = ${extract{2}{:}{${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}}}}
group = mail
create_directory
directory_mode = 770
mode = 660
use_lockfile = no
delivery_date_add
envelope_to_add
return_path_add
directory = “${extract{5}{:}{${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}}}}/mail/$domain/$local_part/.Spam”
quota = ${extract{6}{:}{${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}}}}M
quota_directory = “${extract{5}{:}{${lookup{$local_part}lsearch{/etc/exim4/domains/$domain/passwd}}}}/mail/$domain/$local_part”
quota_warn_threshold = 75%

dovecot_virtual_delivery:
driver = pipe
command = /usr/lib/dovecot/dovecot-lda -e -d $local_part@$domain -f $sender_address -a $original_local_part@$original_domain
delivery_date_add
envelope_to_add
return_path_add
log_output = true
log_defer_output = true
user = ${extract{2}{:}{${lookup{$local_part}lsearch{/etc/exim4/domains/${lookup{$domain}dsearch{/etc/exim4/domains/}}/passwd}}}}
group = mail
return_output

address_pipe:
driver = pipe
return_output

address_file:
driver = appendfile
delivery_date_add
envelope_to_add
return_path_add

address_reply:
driver = autoreply

userautoreply:
driver = autoreply
file = /etc/exim4/domains/$domain/autoreply.${local_part}.msg
from = “${local_part}@${domain}”
headers = Content-Type: text/plain; charset=utf-8;\nContent-Transfer-Encoding: 8bit
subject = “${if def:h_Subject: {Autoreply: "${rfc2047:$h_Subject:}"} {Autoreply Message}}”
to = “${sender_address}”

devnull:
driver = appendfile
file = /dev/null

######################################################################

RETRY CONFIGURATION

######################################################################
begin retry

Address or Domain Error Retries

----------------- ----- -------

                 *           F,2h,15m; G,16h,1h,1.5; F,4d,6h

######################################################################

REWRITE CONFIGURATION

######################################################################
begin rewrite

######################################################################

Email not DKIM Signed (dkim=none reason="message not signed")

========================================================== Summary of Results

DKIM check details:

============================================================== Explanation of the possible results (based on RFCs 7601, 7208)

DKIM Results

========================================================== Summary of Results

Exim configuration file for Hestia Control Panel

We test that $tls_in_sni is a valid domain, by an arbitrary email address [email protected] .

Then, we extract the domain with a function that would fail if the email address is invalid.

If the certificate exists, we will use it, otherwise the default certificate in /etc/ssl will be used.

Custom Filter

ACL CONFIGURATION

Specifies access control lists for incoming SMTP mail

Limit per user for PHP scripts

Limit per email account for SMTP auhenticated users

Deny spam at high score if spam score > SPAM_REJECT_SCORE and delete_spam is enabled

AUTHENTICATION CONFIGURATION

ROUTERS CONFIGURATION

Specifies how addresses are handled

TRANSPORTS CONFIGURATION

RETRY CONFIGURATION

Address or Domain Error Retries

----------------- ----- -------

REWRITE CONFIGURATION

==========================================================
Summary of Results

==============================================================
Explanation of the possible results (based on RFCs 7601, 7208)

==========================================================
Summary of Results
