Fail2ban doesn't work with roundcube

jperkins · August 9, 2024, 8:54am

Please correct me if I am mistaken:
first off fail2ban is disabled for roundcube upon installation

hestiacp/hestiacp/blob/5aeb8ea2159e4e365298e832120ab74f351cc1f7/install/deb/fail2ban/jail.local#L42



          maxretry = 5

          [hestia-iptables]
          enabled  = true
          filter   = hestia
          action   = hestia[name=HESTIA]
          logpath  = /var/log/hestia/auth.log
          maxretry = 5

          [roundcube-auth]
          enabled  = false
          filter   = roundcube-auth
          action   = hestia[name=WEB]
          logpath  = /var/log/roundcube/errors.log
          maxretry = 5

          [phpmyadmin-auth]
          enabled  = true
          filter   = phpmyadmin-syslog
          action   = hestia[name=WEB]
          logpath  = /var/log/auth.log

so you need to change the enabled from false to true in /etc/fail2ban/jail.local

second the regex is not working

I found an old regex from here that works although it is simple

so I edited /etc/fail2ban/filter.d/roundcube-auth.conf

and replaced this line

failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> from <HOST>(?:(?:$[^$]*\))?\. (?:(?! from ).)*(?: user=(?P=user))? in \S+\.php on line \d+ $\S+ \S+$)?$

with this line
failregex = ^Login failed for .* from <HOST>\..*$

then restart fail2ban.

and then upon a bad login in roundcube this line was generated in /var/log/fail2ban.log

2024-08-09 03:45:45,316 fail2ban.filter [4099569]: INFO [roundcube-auth] Found <redacted+ip> - 2024-08-09 03:45:45

just a side note the logging change from from/against happened in 2017. seems like a long time for fail2ban not to catch this

Opened a bug report on this

github.com/hestiacp/hestiacp

[Bug] fail2ban not working with roundcube

opened 08:59AM - 09 Aug 24 UTC

jim-perkins

bug

### Describe the bug fail2ban is not enabled for roundcube and the included rou…ndcube filter regex is not working https://forum.hestiacp.com/t/fail2ban-doesnt-work-with-roundcube/15424/21 ### Tell us how to replicate the bug open up roundcube attempt a bad login notice that fail2ban is not picking it up ### Which components are affected by this bug? Control Panel Backend, Control Panel Web Interface, Mail Security (Antivirus, Antispam), Webmail (Roundcube, SnappyMail), Firewall (Iptables, Fail2ban) ### Hestia Control Panel Version VERSION='1.8.11' ### Operating system debian 12 ### Log capture _No response_

and wondered, if roundcube wasnt installed from source and used the package from debian/ubuntu would this issue have came up. What advantages due we gain from using the source package except maybe the version is kept stable until hestia determines roundcube should be updated. in other words an ‘apt update’ isnt going to update roundcube

sahsanu · August 9, 2024, 10:40am

That won’t work with the op log entry because there isn’t a dot after the host ip:

[08-Aug-2024 17:27:51 +0000]: <tgesrk97> IMAP Error: Login failed for [email protected] against localhost from 192.145.38.206 (X-Forwarded-For: 192.145.38.206). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)

This regex should work for both cases:

failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> against .* from <HOST>.+in \S+\.php on line \d+ \(\S+ \S+\)?$

Technically it doesn’t matter whether it is from or against because <F-USER>.*</F-USER> catches both cases with from or against. It is true that it extracts incorrectly the user but in this case doesn’t matter.

For this case doesn’t matter wheter roundcube is installed directly from source or using OS packages. Here the problem is the roundcube-auth filter used in OS package fail2ban.

jperkins · August 9, 2024, 10:49am

Thanks for the reply and the clearing up the from/against. I can see why you would say the dot wouldnt work in the regex. but it does appear to be working.

roundcube error log
[09-Aug-2024 10:43:46 +0000]: <5gs7d189> IMAP Error: Login failed for baduser against localhost from MYIP (X-Forwarded-For: MYIP). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)

fail2ban log
2024-08-09 05:43:46,063 fail2ban.filter [4099569]: INFO [roundcube-auth] Found MYIP - 2024-08-09 05:43:46

roundcube-auth.conf
root@seeerveeer:~/hestia/conf# cat /etc/fail2ban/filter.d/roundcube-auth.conf
# Fail2Ban configuration file for roundcube web server
#
# By default failed logins are printed to 'errors'. The first regex matches those
# The second regex matches those printed to 'userlogins'
#   The userlogins log file can be enabled by setting $config['log_logins'] = true; in config.inc.php
#
# The logpath in your jail can be updated to userlogins if you wish
#

[INCLUDES]

before = common.conf

[Definition]

prefregex = ^\s*(\[\])?(%(__hostname)s\s*(?:roundcube(?:\[(\d*)\])?:)?\s*(<[\w]+>)? IMAP Error)?: <F-CONTENT>.+</F-CONTENT>$

#failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> from <HOST>(?:(?:\([^\)]*\))?\. (?:(?! from ).)*(?: user=(?P=user))? in \S+\.php on line \d+ \(\S+ \S+\))?$
failregex = ^Login failed for .* from <HOST>\..*$
            ^(?:<[\w]+> )?Failed login for <F-USER>.*</F-USER> from <HOST> in session \w+( \(error: \d\))?$

ignoreregex = Could not connect to .* Connection refused

journalmatch = SYSLOG_IDENTIFIER=roundcube

# DEV Notes:
#
# Source: https://github.com/roundcube/roundcubemail/blob/master/program/lib/Roundcube/rcube_imap.php#L180
#
# Part after <HOST> comes straight from IMAP server up until the " in ....."
# Earlier versions didn't log the IMAP response hence optional.
#
# DoS resistance:
#
# Assume that the user can inject "from <HOST>" into the imap response
# somehow. Write test cases around this to ensure that the combination of
# arbitrary user input and IMAP response doesn't inject the wrong IP for
# fail2ban
#
# Author: Teodor Micu & Yaroslav Halchenko & terence namusonge & Daniel Black & Lee Clemens

jperkins · August 9, 2024, 10:55am

maybe the <HOST> matches the IP and the x-forwarded ip and then matches on the trailing dot.

MYIP (X-Forwarded-For: MYIP).

sahsanu · August 9, 2024, 10:57am

If it works is because fail2ban is capturing <HOST> not only as the ip 203.0.113.1 but the entire string 203.0.113.1 (X-Forwarded-For: 203.0.113.1)

sahsanu · August 9, 2024, 10:57am

You were faster than me

jperkins · August 9, 2024, 11:00am

Lol. But I do think the regex I supplied is too simple to be the final solution.

https://fail2ban.readthedocs.io/en/latest/filters.html#filter-security

timwol · August 9, 2024, 11:00am

Hi

of origen Rouncube
activated = false

I changed it because it didn’t work and put it in
activated = true

All this is out of my level. Sorry but I can’t help you solve it.
If you want that I check something just tell me.

thanks

sahsanu · August 9, 2024, 11:04am

The one I posted should be enough… at least it works in the tests I have done

failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> against .* from <HOST>.+in \S+\.php on line \d+ \(\S+ \S+\)?$

timwol · August 9, 2024, 11:10am

Hi

but then I edit the file roundcube-auth.conf an replace the line?

[quote=“jperkins, post:21, topic:15424”]
so I edited /etc/fail2ban/filter.d/roundcube-auth.conf

and replaced this line

failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> from <HOST>(?:(?:$[^$]*\))?\. (?:(?! from ).)*(?: user=(?P=user))? in \S+\.php on line \d+ $\S+ \S+$)?$

with this line

failregex = ^(?:FAILED login|Login failed) for . against . from .+in \S+.php on line \d+ (\S+ \S+)?$

timwol · August 9, 2024, 11:20am

Hi sahsanu

¿Do I try this line in the route that say jperkins?

failregex = ^(?:FAILED login|Login failed) for . against . from .+in \S+.php on line \d+ (\S+ \S+)?$

greetings

sahsanu · August 9, 2024, 11:28am

Yes, and remember to restart fail2ban after that:

systemctl restart fail2ban

timwol · August 9, 2024, 11:40am

Hi

My failregex has a more line that put jperkins

failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> from <HOST>(?:(?:\([^\)]*\))?\. (?:(?! from ).)*(?: user=(?P=user))? in \S+\.php on line \d+ \(\S+ \S+\))?$
            ^(?:<[\w]+> )?Failed login for <F-USER>.*</F-USER> from <HOST> in session \w+( \(error: \d\))?$

It doesn’t matter?
do I change it’

greetings

sahsanu · August 9, 2024, 12:19pm

Yes but the second line must stay there, change only the failregex line, should look like this:

[INCLUDES]

before = common.conf

[Definition]

prefregex = ^\s*(\[\])?(%(__hostname)s\s*(?:roundcube(?:\[(\d*)\])?:)?\s*(<[\w]+>)? IMAP Error)?: <F-CONTENT>.+</F-CONTENT>$

failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> against .* from <HOST>.+in \S+\.php on line \d+ \(\S+ \S+\)?$
            ^(?:<[\w]+> )?Failed login for <F-USER>.*</F-USER> from <HOST> in session \w+( \(error: \d\))?$

ignoreregex = Could not connect to .* Connection refused

journalmatch = SYSLOG_IDENTIFIER=roundcube

timwol · August 9, 2024, 12:51pm

Hi

My current file roundcube-auth.conf


[INCLUDES]

before = common.conf

[Definition]

prefregex = ^\s*(\[\])?(%(__hostname)s\s*(?:roundcube(?:\[(\d*)\])?:)?\s*(<[\w]+>)? IMAP Error)?: <F-CONTENT>.+</F-CONTENT>$

failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> from <HOST>(?:(?:\([^\)]*\))?\. (?:(?! from ).)*(?: user=(?P=user))? in \S+\.php on line \d+ \(\S+ \S+\))?$
            ^(?:<[\w]+> )?Failed login for <F-USER>.*</F-USER> from <HOST> in session \w+( \(error: \d\))?$

ignoreregex = Could not connect to .* Connection refused

journalmatch = SYSLOG_IDENTIFIER=roundcube

after that I’ve put

systemctl restart fail2ban

and the results

[09-Aug-2024 12:37:32 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:37:50 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:38:04 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:38:36 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:38:52 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:39:10 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:40:46 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)

it doesn’t work
The Ip isn’t banned

greetings

timwol · August 9, 2024, 1:02pm

Hi

On more thing.
The hour isn’t correct. The curretly hour in spain is 14:57 Pm, but in the result is diferent.
It’ something rare.

[09-Aug-2024 12:37:32 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:37:50 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:38:04 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:38:36 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:38:52 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:39:10 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)
[09-Aug-2024 12:40:46 +0000]: <4ss5i6nf> IMAP Error: Login failed for [email protected] against localhost from 77.243.86.16 (X-Forwarded-For: 77.243.86.16). AUTHENTICATE PLAIN: Authentication failed. in /var/lib/roundcube/program/lib/Roundcube/rcube_imap.php on line 211 (POST /?_task=login&_action=login)

greeting

sahsanu · August 9, 2024, 1:26pm

But you are not using the modified regex I’ve posted

sahsanu · August 9, 2024, 1:36pm

That’s because you didn’t configure date.timezone directive in php so it is using UTC instead of CEST. If you want to modify it, edit the php.ini for your php version, for example, for php 8.2, edit this file /etc/php/8.2/fpm/php.ini and replace this:

;date.timezone =

by this:

date.timezone = Europe/Madrid

Once done restart the php-fpm service for your php version, example with 8.2:

systemctl restart php8.2-fpm

And now you will see the right date/time in the logs.

timwol · August 9, 2024, 1:47pm

HI sahsanu

what do I have to put?

greetings

sahsanu · August 9, 2024, 1:49pm

[INCLUDES]

before = common.conf

[Definition]

prefregex = ^\s*(\[\])?(%(__hostname)s\s*(?:roundcube(?:\[(\d*)\])?:)?\s*(<[\w]+>)? IMAP Error)?: <F-CONTENT>.+</F-CONTENT>$

failregex = ^(?:FAILED login|Login failed) for <F-USER>.*</F-USER> against .* from <HOST>.+in \S+\.php on line \d+ \(\S+ \S+\)?$
            ^(?:<[\w]+> )?Failed login for <F-USER>.*</F-USER> from <HOST> in session \w+( \(error: \d\))?$

ignoreregex = Could not connect to .* Connection refused

journalmatch = SYSLOG_IDENTIFIER=roundcube
